Installation Videos

Technical Resource Video – Bridge Crossing Planning & Installation

Proper planning and execution is critical to ensure the pipe installed on the bridge functions properly throughout the duration of it's installment. This video is for informational purposes only and is not to be used as an installation guideline. Contact U.S. Pipe engineers to get fully detailed information around your bridge crossing project.

HDSS Installation On-Site

30" HDSS Ductile Iron Pipe from U.S. Pipe installed using a horizontal directional drill setup. The quick installation of HDSS allows for faster and more reliable assembly and restrained joint assurance. This video is unedited, and it only takes 2 minutes to insert the pipe and restrain it with the HDSS locking segments.

Field Rounding & Jacking of Pipe

U.S. Pipe Ductile Iron installation video for field rounding and jacking of pipe.

TR XTREME Installation

TR-XTREME is the U.S. Pipe Earthquake Resistant Restrained Joint Ductile Iron Pipe (ERDIP). This video highlights the installation procedures for TR-XTREME and shows the expansion and contraction abilities as well as the increased deflection.

30″-64″ HP LOK Installation

U.S. Pipe installation video for HP LOK ductile iron pipe HP LOK ring and joint for 30" through 64" pipe. The HP LOK is a restrained joint pipe for use in high pressure applications.

24″-36″ TR FLEX Gripper Ring Installation

U.S. Pipe 24 inch through 36 inch TR FLEX Gripper Ring installation instructions using a TYTON Gasket.

4″-24″ Field Lok Installation

U.S. Pipe offers the industry leading FIELD LOK 350 restrained joint gasket for TYTON Joint push-on pipe. This video will assist you in the installation.

4″-20″ TR FLEX Gripper Ring Installation

U.S. Pipe TR FLEX gripper ring installation video for ductile iron pipe. The gripper ring allows for restrained joints on field cut pipe or pipe without a weld bead.

24″-36″ TR FLEX Joint Installation & TYTON Gasket

Installation video for U.S. Pipe TR FLEX ductile iron pipe for 24" through 36" using a TYTON gasket. The TR FLEX is a restrained joint pipe with increased deflection.

4″-20″ TR FLEX Installation

Installation video for U.S. Pipe TR FLEX ductile iron pipe for 4" through 20" using a TYTON gasket. The TR FLEX is a restrained joint pipe with increased deflection.

4″-24″ Field Lok Disassembly

This video is to assist you in disassembling your FIELD LOK 350 restrained joint gasket.
